Convex vertical corner correction (correction to horizontal symmetry by
using corners as the center line)
Ș
A
Screen
α Angle of possible projector
motion
Side view
Lens type Vertical lens shift:
Home position
Ș
Side view
Vertical lens shift: Top
Ș
Side view
ELPLM15/ELPLM09/
ELPLS04
20Ëš 8Ëš
ELPLX02/ELPLX02W - -
ELPLU03 11Ëš 2Ëš
ELPLU04/ELPLU02 9Ëš *
ELPLR04 11Ëš -
ELPLW05 12Ëš 3Ëš
ELPLW06/ELPLW04 17Ëš 3Ëš
ELPLW08 14Ëš -
ELPLM10/ELPLM06 22Ëš 13Ëš
ELPLM11/ELPLM07 22Ëš 16Ëš
Lens type Vertical lens shift:
Home position
Ș
Side view
Vertical lens shift: Top
Ș
Side view
ELPLL08/ELPLL07 22Ëš 17Ëš
*Cannot be corrected accurately. Move the lens position to the home position.
Adjustment Range for Projected Images
