evertz 3025SW - Upgrading 3025 SW Firmware

3025SW Master Control Switching & Channel Branding
Page 168 Revision 1.0
Preset/Program
Source Overflow
Source Selection
This key will
automatically re-
purpose itself so that
the current PGM/PST
Source in the upstream
router can always be
shown on the panel.
Note: PGM can only be
changed if the “On-Air
Enable” key is held-down.
Main/Reserve Inputs
Not Supported
Upstream Dest (SP-1)
Source
Not Supported
Upstream Dest (SP-2)
Source
Not Supported
Upstream Dest (SP-3)
Source
Not Supported
Upstream Dest (SP-4)
Source
Not Supported
Emergency Source
Not Supported
Transition Type
Scrolling or Static
Selection
Select the transition
type for the next
transition.
N/A
Transition Speed
Scrolling or Static
Selection
Selects the transition
speed for the next
transition.
N/A
Transition Take
N/A
Start a transition
(tx_start).
N/A
Background Level
N/A
Configure if the PST
video/audio will
transition with the next
transition start.
N/A
Keyer Trans Enable
N/A
Configure if the Keyers
will transition with the
next transition start.
Note: This does NOT apply
to the Internal Branding
Keyer (EMG).
User Transition
Select
User Transition
Selection
Select a pre-defined
user transition.
N/A
Fade to Black/Silence
N/A
Fade the PGM Bus to
black video and audio
silence
N/A
Preroll and
Transition Take
N/A
If the current source
has a pre-roll
associated to it this will
trigger a take with pre-
roll.
Note: This key can be used
also start a transition for no
pre-roll sources.
Preview Transition
N/A
Preview a WIPE
transition on the PST
Bus only.
Note: Only works for WIPE
transitions.
Multi Transition Take
Not Supported
Multi Transition Take
Preroll
Not Supported
