3025SW Master Control Switching & Channel Branding
Revision 1.0 Page 169
A/B Mode Current
State
N/A
Displays the current
internal upstream
switch mode, A/B or
B/A.
N/A
Transition Start Hold
N/A
While this key is held
ON this will stop any
pending transition from
starting until the key is
released.
N/A
Keyer 1 Level
N/A
Puts the selected
keyer on the PST Bus
OR makes an on-air
keyer transitional (go
off-air with next
transition).
N/A
Keyer 2 Level
N/A
Puts the selected
keyer on the PST Bus
OR makes an on-air
keyer transitional (go
off-air with next
transition).
N/A
Keyer 3 Level
Not Supported
Keyer 4 Level
Not Supported
Keyer 1 On-Air
N/A
Toggles the on-air
state if the selected
keyer.
N/A
Keyer 2 On-Air
N/A
Toggles the on-air
state if the selected
keyer.
N/A
Keyer 3 On-Air
Not Supported
Keyer 4 On-Air
Not Supported
Keyer Gain Up
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Gain Up OR the
Current keyer (see
“Keyer” button type)
Gain Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Gain
Up/Down.
Keyer Gain Down
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Gain Up OR the
Current keyer (see
“Keyer” button type)
Gain Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Gain
Up/Down.
