Shuffle Detection Key
Assign to either PGM or
PST Bus.
Key will tally with the
name of the last shuffle
store recalled against
that bus and will also
tally if a manual/M2100
audio shuffle matches a
pre-configured shuffle
store audio mapping.
If a user legend is
defined to the key such
as “Shuf None” this will
be displayed if not
shuffle store is
active/matching to be
displayed in the Shuffle
Detection Key.
Audio Input
(Bus + Channel)
All Buses/Selected Bus
and Audio Channel
Select the required bus
and audio channel.
N/A
Audio Gain Adjust
(Currently Selected)
Adjust Up/Adjust Down
Adjust the audio input
gain of the selected
channel.
Note: Channel selection
using “Audio Input (Bus
+ Channel)” key type.
Mono Mix Toggle
Current Selection
Toggle the Mono Mix
state of the selected
channel.
Note: Channel selection
using “Audio Input (Bus
+ Channel)” key type.
Audio Input Mute
Toggle
Bus and Channel
Number
Toggle the selected
audio channel mute and
un-mute state.
N/A
Audio Bus Mute Key
Bus, Mute Enable/Mute
Disable
Toggle the selected
audio bus mute and un-
mute state.
N/A
Audio Input Store
Recall
Bus and Store Number
Apply a pre-configured
audio bus store to the
selected bus.
Note: These are
configured in the “Audio
Input Defaults/Stores”
tab of EMC-Setup.
Audio Inp. Store Item
Default
Bus
Sets the audio bus back
to default as configured
in EMC-Setup.
N/A
Wipe Preset
Scrolling or Preset
Number 1 to 5
Select a wipe preset.
Note: Wipe Presets are
configured in the
“Wipes” tab of EMC-
Setup.
Wipe Type
(scrolling)
Select the wipe type.
N/A
Wipe Width Up
N/A
Adjust the wipe width up.
N/A
Wipe Width Down
N/A
Adjust the wipe width
down.
N/A
Wipe Softness Up
N/A
Adjust the wipe softness
up.
N/A
Wipe Softness Down
N/A
Adjust the wipe softness
down.
N/A
Wipe Direction
(scrolling)
Adjust the wipe direction
to either normal, inverted
or flip-flop.
N/A
Wipe Angle Up
N/A
Adjust the wipe angle up.
N/A
Wipe Angle Down
N/A
Adjust the wipe angle
down.
N/A
