Multimeter Tests
116 MAX-635G
Voltage
Current Group is the current test group name, for example
Multimeter.
Current Test displays the test being measured. Here you can switch to
another test from the given list. However, this action will terminate the
ongoing measurement test.
Selected Pair allows you to select All Pairs or a single wire pair for
measurement.
Termination Resistance defines how much resistance the tester uses
to connect to the line and measure voltages.
Threshold Settings button opens a new page that allows you to set the
DC voltage thresholds for each pair.
Result displays a snapshot of the pass/fail status and volts for each
continuous DC pair.
Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
