EXFO MaxTester 635G - Using the MaxTester

Introducing the MAX-635G
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 3
Using the MaxTester
Using the MaxTester
The MaxTester is tested IEC IP54 which means that it is not affected by dust
or water splashing against the enclosure from any direction. This
protection is only valid when both side doors are properly closed. If the
equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
The MaxTester is equipped with a series of interfaces shown in the
following views, for single and dual battery option (GVXAA and GVXAB
models only):
 Left side
 Single battery
 Dual battery
USB Host Port
USB Client Port
SD Card (not used)
Head Set Jack (2.5 mm)
Door
USB Client Port
Door
USB Host Port
SD Card (not used)
Head Set Jack (2.5 mm)
DC Power
Battery pack
