Setting Up Copper Tests
68 MAX-635G
Dialer Function
Dialer Function
The Dialer function provides a dial-up path from the
MAX-635G to another tester (or quiet termination or
silent switchman) through a switched circuit network.
DTMF (dual-tone multi-frequency) transmission is
enabled via the phone keypad allowing you to place
POTS calls. The dialer can be accessed from the
Copper Main or Multimeter (if FED option enabled)
pane and is also integrated into individual test screens
to give you quick access to the manual dialer function,
speed dial and last dialed lists, without exiting the
current test application.
To access the Dialer function:
1. On the Home pane use the up/down arrow keys to highlight Copper
Test, then press .
2. From the Copper Main or Multimeter (if FED
option enabled) page select Dialer and press .
Dialer
Dialer provides the following functions:
The means to call and signal voice switch test
functions, such as drop battery, quiet line, and
more.
It is integrated with POTS Auto Test and other
manual test screens for easy access to the switch
functions during those tests. For example, when
testing for load coils, you can remove the line battery and use the
dialer function to signal the switch to drop battery, and then run the
load coil test.
