Multimeter Tests
124 MAX-635G
Current
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
Continuous DC Page
The Continuous DC function measures each pair,
displaying and updating results in real time, until you
stop the test. The last valid results then remain
displayed. Significant fluctuations while this test is
running can indicate intermittent swinging, contact or
wet faults.
To view all lead combinations right away:
Press the Snapshot function key.
Continuous AC and Continuous DC are run
synchronously. Press Start/Stop on the keypad to run
the test.
Current Group is the current test group name, for example
Multimeter.
Current Test displays the test being measured. Here you can switch to
another test from the given list. However, this action will terminate the
ongoing measurement test.
Selected Pair allows you to select All Pairs or a single wire pair for
measurement.
Termination Resistance is a read-only value of 430 Ω that defines how
much resistance the tester uses to connect to the line.
