Multimeter Tests
132 MAX-635G
Resistive Balance
 Threshold Settings button opens a new page that allows you to set the
resistive balance thresholds.
 Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
Resistive Balance Threshold Settings
The Threshold Settings page allows you to set the
Resistive Balance (
Ω) Threshold values. The
threshold is a programmable value you can use as an
on-screen indicator in each test when a measured
value is too high or too low.
 Type is the threshold limit for each pair: either
Maximum or Minimum.
 Enabled is a flag to use the current threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
