Multimeter Tests
144 MAX-635G
Capacitance/Opens
Capacitance/Opens Threshold Settings
The Threshold Settings page allows you to set the
Capacitive Balance Threshold parameters for the
test between 0 and 100 %. The threshold is a
programmable value you can use as an on-screen
indicator in each test when a measured value is too
high or too low. POTS and internet circuits should be
95 %, and higher speed broadband circuits 97 % or
98 % if possible.
Type is the threshold limit for each pair: either
Maximum or Minimum.
Enabled is a flag to use the current threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
