Frequency Tests
238 MAX-635G
Load Coils
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
TDR
The Load Coils TDR function provides a shortcut to
the TDR test. A dialogue box opens, warning that you
are about to leave the Load Coils test. TDR results
captured while running Load Coils will be available
upon loading TDR. Please go to TDR on page 253 for
information on this test.
