TDR
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 257
Continuous
Result displays the distance to the most significant reflection, in text
and graphical measurements. The distance (Delta) value between
cursor and marker is also displayed at the top of the graph.
Test Status displays the current state of measurement or an error
message.
Load Trace function key opens a new page that allows you to load a
trace from a list of previously saved TDR tests
Clear Trace function key deletes the loaded trace from the graph.
To select the parameter values in Portrait Mode:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view, select the options, or
increase/decrease values.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
