RFL
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 285
Separate Good Pair
Current Test displays the test being measured. When FED is Enabled,
the FED icon and numeric state are displayed beside the Current Test.
Cable Setup button opens a new page that allows you to set the cable
parameters for the Current Test. Press to open the page.
Result displays the separate good pair RFL test results. Based on the
cable condition, corresponding values are added into the diagram at
their specific positions. Test result units are dependent on Standard in
Setup/Application Settings.
Distance to strap (DTS).
Resistance to strap (RTS).
Distance from fault to strap (DFTS).
Resistance from fault to strap (RFTS).
Resistance to fault (RTF).
Distance to fault (DTF).
Faulted cable (FC).
Resistance at fault (Rf) is resistance from the fault to the resistance
wire.
Voltage at fault (Vf).
