Setting Up the MAX-635G
46 MAX-635G
Wi-Fi Test
Details of the selected Network Name include:
Signal (RSSI) strength may list one of the following levels with the
table cell shown in the corresponding colour:
No Signal (< -90/black)
Very Low (-90 to -82/red)
Low (-81 to -72/red)
Good (-71 to -68/orange)
Very Good (-67 to -58/yellow)
Excellent (> -58/green)
Channel displays the Wi-Fi channel number and frequency.
Security displays one of the following encryption and authentication
types: NONE, WEP-OPEN, WEP-SHARED, WPA-TKIP, WPAPSK-TKIP,
WPA2-TKIP, WPA2PSK-TKIP, WPA-AES, WPAPSK-AES, WPA2-AES,
WPA2PSK-AES.
Network Type is either Access Point (the infrastructure network or
router) or Adhoc (spontaneous).
To navigate to a Wi-Fi network and view the details:
1. Press to get into the list.
2. Press the up/down arrow keys to select a network and view its details
below.
