2. Project management
2−25
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
The WinPISA print−outs contain:
Print−out
Contents
Project information The composition of the current project, basi
cally the content of the project window, in
addition to the title and comment entered
when the project was created.
Hardware
information
The hardware in the project and all para
meters set for the hardware in WinPISA.
Programs Complete print−out of the user programs, as
well as the program no., its title and descrip
tion.
Position list All positions in the position list, with index,
symbol name and comment.
Graphics The print−out of graphics corresponds to the
display in the graphics window but is scaled
according to the paper size.
It can be worthwhile to set the printer page
layout to landscape when printing out
graphics.
To print the current project or parts of a current project:
1. Select [Project] from the [File] [Print] menu.
2. Select the components to be printed from Selection" in
the Print project" dialogue window.
