3. Project planning
3−6
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
Selecting a pneumatic axis
The cylinder type, diameter, length, valve type and measuring
system of the specified axes are shown under Planned axes".
Select the valve−cylinder measuring system combination
used.
If the list does not contain an axis with the correct length,
select the axis with the next smaller length (see specified
length range
under Cylinder type").
The length entered in the specification corresponds to the
minimum length for the valve−cylinder combination.
Example
You have an 40 mm diameter axis which is 600 mm long. In
this case select the axis DGP−40−250...850; ∅40; L250;
MPYE−5−1/8HF−010B" under Projected axes" in the list.
