4. Commissioning positioning systems
4−60
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
8. Mark the position on the axis. Accept the position with
Set position". The position value is entered in the field
Position 2 under Calibrating data".
In the field Length" or Angle" the length or the angle
between the calibration points ascertained by the measu
ring system are displayed.
9. Measure the distance between or
the angle of the two
calibration points (e.g. with a tape measure). Enter the
value measured in the field Length" or Angle".
The values measured and the values ascertained by the mea
suring system may deviate max. 10 % from each other.
10. Accept the value entered with Calibrate".
In order to calibrate further axes,
carry out steps 4 to 10
again.
