Contents and general instructions
XXVI
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
Version See sectionWhat has been changed?Identification
as from
4.82
New feature
as from OS 4.8
2
At least WinPISA 4.41 is recommended for
this version.
 The DNCI drive family with incremental
measuring system is supported.
 Reference travel for pneumatic axes has
been introduced } G74.
 Channel 5 has been introduced in the con
figuration data for the digital nominal value
specification via the field bus } M10.
 Command M37 can be parametrized with
values (mass value) from the position regis
ters @n.
 The work item mass in the basic status"
(the axis) has also been introduced in the
configuration data. You can then define the
mass load which is to be effective when the
system is switched on. The dialogue for the
axis identification travel has been adapted
accordingly in WinPISA 4.41.
 The commands M10 and M11 can be
parametrized with values from the position
registers @n.
 Serious fault" will no longer be generated
if there is undervoltage in the load voltage.
The exchange of data with the measuring
system has been retained and the counter
status of the incremental measuring sys
tem will continue to be updated, as long as
the supply voltage is applied and providing
there is no other serious system fault."

System manual
for the SPC200
5.4
5.4
5.4
System manual
for the SPC200
5.4

as from
4.90
New feature
as from OS 4.9
0
At least WinPISA 4.50 is recommended for
this version.
 Support of fieldbus module type
SPC200−COM−DN2
 System status flags F88 and F89 as status
flags for Task A and B.
 CP−I/O modules type CP..−CL are supported.

Description of
fieldbus module
5.3.6

as from
4.93
New feature
as from OS 4.9
3
At least WinPISA 4.51 is recommended for
this version.
 Error messages via the fieldbus can be sup
pressed through paramaterization (no stop
of the PLC).
 Stop behaviour can be configured.

Description of
fieldbus module
4.3.3
