3. For communication with the SPC200, set the serial inter
face used and the desired baud rate under [Online] [Data
transmission].
When the SPC200 is connected, you can test the data
transmission. To do this activate [Online] [Online mode].
The set values are correct unless an error message is
shown here.
Step 1
Simulate the existing hardware configuration in a WinPISA
project
(see also sections 1.7, 2.1, 2.2 and 4.2)
Read out hardware configuration of the SPC200
(recommendation)
1. Activate online mode (command [Online] [Online mode]).
If your hardware configuration differs from the saved nominal
configuration, you will receive a fault message (00004001).
Quit the fault message with OK".
The deviations are displayed in the dialogue window Save
actual as nominal configuration?"
Check to make sure that the configuration displayed is cor
rect. If necessary, check to make sure that the status LEDs of
all connected modules light up and that the modules are the
refore recognized. With Yes" you accept the
actual configu
ration as the nominal configuration.
If the axis assignment has been modified, a message will be
displayed stating that a data reset is necessary for this. If
there are no data in the SPC200 which must first be saved in
a WinPISA project, you can carry out the data reset
with
Continue".
When leaving the factory, the SPC200 is prepared for saving
the current hardware configuration in the first startup phase
automatically as the reference configuration (there is no error
message).
