Contents and general instructions
XXX
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
Commissioning a pneumatic axis
Step 2
Set the axis−specific parameters and load the project into
the SPC200 (pneumatic axis)
(see also section 4.3)
1. Set the axis and application parameters. To do this mark
the icon by the desired axis in the project window and
select the command [Configure] in the menu [Edit]. Now
set the axis and application parameters correctly.
You will
find explanations on the individual parameters in the
WinPISA help.
2. If necessary, set the axis and application parameters for
further axes as described under 1.
Please note
Controller parameters are not usually modified.
3. If necessary, activate the online mode (command [Online],
[Online mode]).
If your hardware configuration differs from the saved ref
erence Configuration, you will receive an error message
(00004001). If the set configuration corresponds to the
actual configuration, this will become the reference con
figuration when the project
is loaded.
4. Load the project (command [Online] [Download] [Project]).
