6. Diagnostics and optimization
6−37
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
4. Select [Set/Delete stopping point] from the [Online]
[Measurement] menu to set the stopping point for the
measurement, or click on the Set/delete stopping point
for measurement" button in the toolbar. The NC record is
identified by the character **".
5. Select the NC record at which you wish to start continu
ous operation.
6. Select [Startcontinuous
run] from the [Online] [Control
commands] menu or by click on the Start continuous
run" button in the toolbar to start continuous operation.
Once the measurement values have been uploaded from the
SPC200, these become available as Online measurement
data" and can be stored or displayed as a graphic.
Single step To record measurements in
Single Step mode:
1. Select [Single step mode] from the [Online] [Measure
ment] menu or click on the Switch on measurement at
each single step" button in the toolbar to activate
measurement in Single step mode.
2. Select the NC record for which measurement values are to
be recorded.
3. Execute the NC record. Do this by
selecting [Executestep]
from the [Online] [Controlaxes] menu or by clicking on the
Executestep" button in the toolbar.
The measurement values for the selected NC record will
be recorded.
The measurement data will be uploaded from the SPC200
automatically once measurement is completed.
Once the measurement values have been uploaded from the
SPC200, these become
available as Online measurement
data" and can be stored or displayed as a graphic.
