FOR-A MFR-3000 User Manual

146
10-1-12. MFR-GPI
Number of
Connection
Max. 128 (including Main, Remote and GPI units)
Interface
MFR-LAN
10/100BASE-TX RJ-45 x 1
(Ethernet hub is needed for Main and multiple unit connections.)
SERVICE
RS-232C: 9-pin D-sub (male) x 1 (for maintenance)
GPI IN
/TALLY OUT
37-pin D-sub (female) x 4
128-input/output (user assignable)
SERIAL 1-4
RS-232C/422 (selectable): 9-pin D-sub (male) x 4
Temperature
0°C to 40°C
Humidity
30% to 85% (no condensation)
Power
+12VDC pin connector x 2 (redundant power supply in standard
configuration)
Power Consumption
100 V AC to 120 V AC: 8 VA (4 W)
200 V AC to 240 V AC: 13 VA (6 W)
Dimensions
430(W) x 44(H) x 110(D) mm EIA 1 RU
Weight
2 kg
Consumables
AC adaptor: Replace every 5 years
10-1-13. MFR-TALM
Number of
Connections
Max. 128 (including Main, Remote and GPI units)
Interface
MFR-LAN
10/100/1000BASE-T RJ-45 x 1
(Ethernet hub is required for Main and multiple unit connections.)
PC-LAN
10/100BASE-TX RJ-45 x 1 (for PC or other external devices)
GPI IN
/TALLY OUT
37-pin D-sub (female) x 1
32-input/output (user assignable)
RS-422
9-pin D-sub (male) x 4
Temperature
0°C to 40°C
Humidity
30% to 85% (no condensation)
Power
+12 V DC pin connector x 2 (redundant power supplies in standard
configuration)
Power Consumption
100 V AC to 120 V AC: 17 VA (9 W)
200 V AC to 240 V AC: 20 VA (9 W)
Dimensions
212(W) x 44(H) x 161(D) mm EIA 1 RU half size
Weight
2 kg
Consumables
AC adaptor: Replace every 5 years
