FOR-A MFR-3000 User Manual

111
6-2-3. Simultaneous Switching Using the Take Function
The TAKE button on the remote control panel allows you to simultaneously switch preset
crosspoints.
► See section 5-4-3-12 “BTN ASSIGN” for details on assigning the TAKE button.
 Executing a TAKE
See the Ex. 1) and Ex. 2) in section 6-1-4. “Crosspoint Switching Using TAKE Function” for
the procedure.
6-2-4. Simultaneous Switching by the Link Function
The LINK button on the remote control panel allows you to simultaneously switch crosspoints
associated with a specific crosspoint.
Pressing the LINK button enables or disables the Link function. The LINK button is
highlighted with a bright background when the function is enabled.
► See section 5-4-3-12 “BTN ASSIGN” for details on assigning the LINK button.
If the Link function is turned on, selecting a trigger crosspoint switches the slave crosspoints
with it. The trigger and slave crosspoints can be assigned using Web-based Control.
► See [Web-based Control: Link Settings page] for more details.
6-3. Lock
Function operation and crosspoint changes can be disabled by the Lock function.
 LOCK Function
The Lock function is a function that inhibits the use of function buttons or crosspoint changes.
There are three types of Lock functions.
6-3-1. LOCK LOCAL
The Lock Local function inhibits operation of buttons and menus that change the source
channel or sets or executes Take switching on the unit that enabled the Lock function.
(Selecting destination channels is not inhibited.)
This function is used in protecting the system from unintended operation.
 Enabling LOCK LOCAL
(1) Assign LOCK LOCAL to a button on the control unit.
► See section 5-4-3-12 “BTN ASSIGN” and 5-5-2. "Button Assignment Change."
(2) Press the assigned LOCK LOCAL button to enable the Lock Local function.
* Operations are locked for units in black boxes and unlocked for units in white boxes.
RU (Local)
RU
RU
RU
MU
LOCK OTHER function
LOCK ALL function
Inhibits source
channel and function
button operation
Inhibits operation on own unit
LOCK LOCAL function
Inhibits the specific
destination channel
related operation
Inhibits operation from other units
Inhibits operation form other groups.
Inhibits operation for all units
