FPT F32 MNS - Page 149

SECTION 4 - MECHANICAL OVERHAUL
33
F32 SERIES
Pri nt P2D32F005 E Base - April 2009
PART
TORQUE
Nm kgm
Alternator
group
Support fast ening to block (M10x1.5 6g x 50-60) 50±5 5±0.5
Alternator fastening (screw + nut) 50±5 5±0.5
Push rod fixing 50±5 5±0.5
Alternator push ro d fixing (screw + nut ) 50±5 5±0.5
Support fast ening to block (M10x1.5 6g x 35) 50±5 5±0.5
Manoeuvre
hook
Front hook fastening 50±5 5±0.5
Rear hook fastening 70±7 7±0.7
LDA
Manifold side pipe fastening 15±1.5 1.5±0.15
Pump side pipe fastening 15±1.5 1.5±0.15
Sensors
Time impulse transmitter fastening 10±1 1±0.1
Oil pressure sensor fastening 28±2.8 2.8±0.28
Thermometric switc h fastening 36±3.6 3.6±0.36
Water temperature sensor fastening 25±2.5 2.5±0.25
Conical threaded cap 25±2.5 2.5±0.25
Support fixing 25±2.5 2.5±0.25
Air pressure sensor fixin g 10±1 1±0.1
Injection pump
Pump gear fixing
- pre-tightening
- tightening
18±1.8
90±9
1.8±0.18
9±0.9
Stud bolt for injection pump 4±0.4 0.4±0.04
Fuel pump retaining nut 25±2.5 2.5±0.25
High
pressure
Fastening to pump and injector 28±2.8 2.8±0.28
Pipe fastening screws 10±1 1±0.1
Revi - 12.2012
