SECTION 4 - MECHANICAL OVERHAUL
F32 SERIES
Base - April 2009 Pri nt P2D32F005 E
PART
TORQUE
Nm kgm
Turbo
blower
Collector fastening screw nu t s 28±2.8 2.8±0.28
Oil delivery inlet fixing 25±2.5 2.5±0.25
Delivery pipe fastening screw nut 28±2.8 2.8±0.28
Exhaust pipe fixing to heat exchanger 25±2.5 2.5±0.25
Exhaust pipe fixing to turbo 15±1.5 1.5±0.15
”Cooling
pipe
Water pipe fixing to the heat exchanger 25±2.5 2.5±0.25
Water pipe fixing to t he support 25±2.5 2.5±0.25
Threaded cap (F5CE9484) 28±2,8 2.8±0.28
External
EGR
Heat exchanger fastening to valve unit 25±2.5 2.5±0.25
Heat exchanger fastening to throw 25±2.5 2.5±0.25
EGR fastening to intake manifold 25±2.5 2.5±0.25
Valve fixing 10±1 1±0.1
Manifold fastening nut screws 25±2.5 2.5±0.25
Threaded union 75±7.5 7.5±0.75
Oil level check
Oil pressure con trol valve fastening 60±6 6±0.6
Oil level dipstick fastening (F5CE9484) 35±3.5 3.5±0.35
Stirrup
Flange fasten ing to block (F5CE9454/9484) 10±1 1±0.1
Stirrup fastening to block (F5CE9454/9484) 25±2.5 2.5±0.25
Stirrup fastening to block (F5CE5454) 10±1 1±0.1
Oil filter
body
Cartridge union 45±4.5 4.5±0.45
Oil filter fastening 25±2.5 2.5±0.25
Oil filter c artridge fastening 30±3 3±0.3
Oil pump fixing
- pre-tightening
- tightening
6±0.6
35±3.5
0.6±0.06
3.5±0.35
Heat
exchanger
Threaded caps 45±4.5 4.5±0.45
Exchanger unit fixing 25±2.5 2.5±0.25
Heat exchanger fastening 25±2.5 2.5±0.25
Temperatu
re regulator
Thermostat un it fixing 25±2.5 2.5±0.25
Bleed vent fixing 40±4 4.0±0.4
Water pump fastening 25±2.5 2.5±0.25
Fan support
Bearing fixing 40±4 4.0±0.4
Fan support fixing 25±2.5 2.5±0.25
Pulley fixing 40±4 4±0.4
Control outlet rear cover fastening 25± 2.5 2.5±0.25
Revi - 12.2012
