Inserting a screwdriver in th e blow-by pipe (1) t ry to rotate
the blow-by alternatively in both c lockwise and
counterclockwise directions (1) up to when it makes free
from the hold of the sealant.
Figure 69
133194
To remove the blow-by (1) fro m the rocker cover (2) it is
necessary to free the elements from the hold of the sealant.
- With special hot air device (3) heat the concerned area
between blow-by and cover.
Figure 70
133195
Figure 71
133196
Remove the blow-by (1) from the rocker cover (2).
Figure 72
133197
Clean the blow-by seat on the rocker cover (1) from possible
traces of sealant.
Handle with suitable protections; hot parts.
SECTION 3 - INDUSTRIAL APPLICATION
27
F32 SERIES
Pri nt P2D32F005 E Base - April 2009
