Franke Flair Service Manual

Flair Preventive Maintenance
Groupe
Art. Nr
Amount
Description
Work
service 1 service 2 service 3
10000 20000 40000
1 = Replace 2 = Clean 3 = Adjust
4 = Control (Replace when needed)
Thermoblock
1P 315 172 1 Sensor thermoblock complete (S - - 1
1P 315 518 1 Temp. Sensor steam Flair 0035584 - - 1
Brew Unit
1P 315 174 1 Brew unit assembled 2 1 1
1T 310 382 1 O-Ring Silicon 36,09 x 3,53 4 - -
1P 315 415 1 Drainvalve cpl. 4 - -
1P 315 149 1 Encoder 97 - 1 1
Water flow-
valves
Water softener (when installed) 1 1 1
1P 315 082 1 Inner distributing collar 1 1 1
1P 315 629 1 Hose silicone 4 4 4
1P 315 080 2 Flowmeter 4 4 4
1P 315 067 2 Pump 230V 4 4 1
Grinders
1P 315 058 2 Grinder unit 230V assembled 4 4 1
Outlet
1L 296 485 2 Silicone hose ID= 3 mm 1 1 1
1P 315 125 1 Silicone hose 3x1x200mm 1 1 1
1P 315 536 1 Outlet pipe coffee 1 1 1
Cappu
1P 315 603 1 Sparepart kit Cappu 0040279 1 1 1
1P 315 604 1 Sparepart kit Milk 0040280 1 1 1
1L 296 485 2 Silicone hose ID= 3 mm 1 1 1
Descaling if needed if needed if needed
TD-100647.xls

Franke Flair Specifications

General

Type	Espresso Machine
Pump Pressure	15 bar
Product Type	Coffee Maker
Brand	Franke
Model	Flair
Voltage	220-240 V
Frequency	50-60 Hz
Material	Stainless Steel
Programmable	Yes
Auto Shut-off	Yes
Filter Type	Metal Filter
Coffee Output	Single or Double Espresso
