TD-100343.doc
50
4.17. Coffee dispenser micro switch
4.17.2. Replacing the micro switch
Removing the micro switch
Remove front panel as described in
Chapter 4.2.1.
Take out dispenser chute
CAUTION! Disconnect cable connectors
beforehand!
Unscrew screw
Remove cover
Replace micro switch
