Fronius IG Plus A 3.0-1 UNI - Page 53

51
EN-US
1 2
1 2
2
1/2 in.
1
DC+
5
3
1
6x
2
3
4
DC+
1.33 ft. lb.
6
3
1/2 in.
2
1
DC-
7
2
3
6x
4
3
1
DC-
1.33 ft. lb.
8
NOTE! Form a min. 4 in. wire loop using all wires.
CAUTION! Danger of damaging the inverter by overload. Before start-up opera-
tion make sure that there is a conductive slug in each fuse holder for string fuses.
- Insert conductive slugs only with a fuse cover in the respective fuse holder
- Do not operate the inverter without fuse covers
