130
Job-Data
Job data The Job data entry is only displayed if the FP Job function package is present in the power
source.
In the "Job data" entry,
- existing welding system jobs can be viewed
- existing welding system jobs can be optimised
- jobs stored externally can be transferred to the welding system
- existing jobs in the welding system can be exported as a PDF * or CSV file
Job overview The job overview lists all jobs stored in the welding system.
Clicking on a job displays the data and parameters stored for this job.
Job data and parameters can only be viewed in the job overview. The column width for pa-
rameters and values can be easily dragged and adjusted with the mouse pointer.
Other jobs can easily be added to the list with the data listed by clicking on the "Add col-
umn" button.
This offers a simple way of comparing the values from various jobs.
Editing a job Existing welding system jobs can be edited.
Click on "Edit job"
Click on the job to be amended in the list of available jobs
The selected job is opened and the following job data is shown:
- Parameter
The parameter currently stored in the job
- Value
The values of the parameter currently stored in the job
- Change value to
To enter the new parameter value
- Setting range
Possible setting range for the new parameter values
Amend the values accordingly
Save / Delete adjustments, Save as / Delete job
As an aid when editing a job, other jobs can be easily added to the list with the data dis-
played by clicking on "Add column".
1
2
3
4
