81
EN
The Setup menu
General The Setup menu provides easy access to the knowledge base in the power source and to
additional functions. The Setup menu can be used to make simple adjustments to the weld-
ing parameters to suit the various job settings.
The following can be found in the Setup menu:
- all setup parameters that have an immediate effect on the welding process,
- all setup parameters needed for making the preliminary settings on the welding sys-
tem.
The display of the parameters and the ability to change them depends on the selected
menu and the current settings for the welding process and operating mode.
Parameters that are not relevant to the current settings are greyed out and cannot be se-
lected.
Accessing the
Setup menu
Press Menu key
The Setup menu appears.
To leave the Setup menu, press the Menu key again
The current welding parameters will be displayed.
1
1
2
