MagicWave 230i
MW 230i MW 230i MV
Mains voltage U
1
1 x 230 V 1 x 120 / 230 V
Mains voltage tolerance ± 15% ± 15%
Grid frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 16 A 16 A (U
1
= 230 V)
20 A (U
1
= 120 V)
Mains connection
1)
Z
max
on PCC
3)
= 273 mOhm
Z
max
on PCC
3)
= 273 mOhm
Cos phi 0.99 0.99
Primary circuit (at 100% D.C.
2)
)
TIG 3540 VA 3540 VA (U
1
= 230 V)
2390 VA (U
1
= 120 V)
Electrode 3540 VA 3540 VA (U
1
= 230 V)
2410 VA (U
1
= 120 V)
Welding current range
TIG 3 - 230 A 3 - 230 A
Electrode 10 - 190 A 10 - 190 A
Welding current at
10 min/40 °C (104 °F) 35% D.C.
2)
230 A
4)
190 A
5)
230 A
4)
(U
1
= 230 V)
170 A
4)
(U
1
= 120 V)
190 A
5)
(U
1
= 230 V)
120 A
5)
(U
1
= 120 V)
10 min/40 °C (104 °F) 60% D.C.
2)
195 A
4)
150 A
5)
195 A
4)
(U
1
= 230 V)
140 A
4)
(U
1
= 120 V)
150 A
5)
(U
1
= 230 V)
105 A
5)
(U
1
= 120 V)
10 min/40 °C (104 °F) 100% D.C.
2)
165 A
4)
120 A
5)
165 A
4)
(U
1
= 230 V)
120 A
4)
(U
1
= 120 V)
120 A
5)
(U
1
= 230 V)
85 A
5)
(U
1
= 120 V)
Open circuit voltage 100 V 100 V
Working voltage
TIG 10.1 - 19.2 V 10.1 - 19.2 V
Electrode 20.4 - 27.6 V 20.4 - 27.6 V
Striking voltage (U
p
) 9.6 kV 9.6 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Overvoltage category III III
Pollution degree according to IEC 60664 3 3
EMC Emissions class A
6)
A
6)
Insulation class B B
Dimensions L x W x H (with handle) 558 / 210 / 369 mm
22.0 / 8.3 / 14.5 in.
558 / 210 / 369 mm
22.0 / 8.3 / 14.5 in.
Weight 17.0 kg
37.5 lb.
16.5 kg
36.4 lb.
Marks of conformity S, CE S, CE
