Fronius MagicWave 190 User Manual

27
EN
Control panel
General
NOTE!
Due to software updates, you may find that your device has certain functions that
are not described in these operating instructions or vice versa.
Individual illustrations may also differ slightly from the actual controls on your device, but
these controls function in exactly the same way.
Safety
WARNING!
Danger from incorrect operation.
Possible serious injury and damage to property.
► Do not use the functions described here until you have read and completely under-
stood these Operating Instructions.
► Do not use the functions described here until you have fully read and understood all of
the Operating Instructions for the system components, in particular the safety rules!
Control panel
(1)(2)(3)(4)(5)(6)
(7) (8) (10)(9)

Fronius MagicWave 190 Specifications

General

Brand	Fronius
Model	MagicWave 190
Category	Welding System
Language	English
