60
Setting range: 15 - 50%
Factory setting: 35%
15: highest fusing power, lowest cleaning action
50: highest cleaning action, lowest fusing power
Effect of the balance on the waveshape:
Electrode diameter
Setting range: Off; 1.0 - 4.0 mm
Factory setting: 2.4 mm
Cap mode
on MagicWave only
Setting range: off / on
Factory setting: off
off
Automatic cap-shaping function is deactivated
on
For the entered diameter of the tungsten electrode, the optimum cap is formed during the
welding start.
A separate cap-shaping action on a test workpiece is not required
.After this, the automatic cap-shaping function is reset and deactivated again.
+
-
t (s)
I (A)
35% 50% 15%
2.4mm
off
