- 60 - eBike II, eBike II L, eBike II EL 2018112-069 Rev. F
MountIng tHe MaIn support fraMe
• Assemble the main support frame by plugging the two
angled piped in the appropiate counter parts (marked
1 /1 and 2 / 2 until the lock and clamp indexing
plunger clicks into place
• Fix the connections by clockwise screwing the plunger
• Turn-over the main support frame and shift it under
the ergometer
Hint
The support frame should lie symmetrically under the ergometer.
