Figure 13-13 Positioner and receiving hole
2. Press the Lock Lever down so that the pin goes into the hole. Press down enough to lock up
(Figure 13-14).
Figure 13-14 Lock Lever pressed down and in lock position
3. Lock the other side.
Unlock the positioner by treading the cap of the lock lever (as show in Figure 13-13) and the lock lever will
rebound automatically.
