Job Card D/R A141 - Image Receptor/Digital Detector
5 PREREQUISITES
WARNING
Before installing the new detector, you must leave it packed for at least one day so that it
does not suffer from condensation.
• Pull out the Bucky and remove it from the Detector.Switch off the Gantry power.
• Remove the Arm and Detector covers (see Job Card PHY A044 - Remove/Reinstall Gantry Covers
on page 523).
• Switch on the Gantry power.
• Set the arm to an intermediate height.
• Rotate the arm to between a working position of –45° to + 45°.
!
Notice:
Never rotate the arm outside of the range –45° to + 45° when installing the Digital Detector. If the
coolant pipes are not secured properly and if this arm angle range is not respected, there is a risk
of coolant entering the inner workings of the Digital Detector.
• Switch off the Gantry power.
• Remove the Arm covers (Refer to Job Card PHY A044 - Remove/Reinstall Gantry Covers on page
523).
• Remove the Generator covers (Refer to Job Card PHY A042 - Remove/Reinstall Generator Covers
on page 513).
• Switch off the Conditioner.
