GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A204 - Lift Potentiometer
Page no. 1175 Chapter 9
JC-DR-A-204.fm
Job Card D/R A204 - Lift Potentiometer Chapter 9
1SUPPLIES
Lift Potentiometer
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 30 minutes (incl. calibrations and functional checks)
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5 PREREQUISITES
• Raise the arm to an intermediate height to access the lift
potentiometer (1).
• Switch off the Gantry power.
• Remove the covers (See Job Card PHY A044 - Remove/
Reinstall Gantry Covers on page 523).
• Loosen and remove the Gantry curtain under the arm (See
Job Card D/R A208 - Gantry Curtains on page 1193).
1
To Next Page
