GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A150 - System Fuses
Page no. 1109 Chapter 9
JC-DR-A-150.fm
Job Card D/R A150 - System Fuses Chapter 9
1SUPPLIES
Fuses, according to the table below:
Sub-system location Board/Location (illustration ref.) Fuse Specification Fuse Part
Number
Generator
(Conditioner cabinet
part)
Mains Distribution Assembly - F1 (illustration 1) 250 Vac, 10 A, Delay 99183979
Mains Distribution Assembly - F2 (illustration 1) 250 Vac, 5 A, Delay 99183923
Mains Distribution Assembly - F3 (illustration 1) 250 Vac, 1.6 A, Delay 99183925
Mains Distribution Assembly - F4 (illustration 1) 250 Vac, 5 A, Delay 99183923
Generator
Generator Command Board - F1 (illustration 2) 250 Vac, 2.5 A, Delay 99194291
Generator Command Board - F2 (illustration 2) 250 Vac, 2.5 A, Delay 99194291
Generator Command Board - F3 (illustration 2) 250 Vac, 2.5 A, Delay 99194291
Supply Command Board - F1 (illustration 3) 250 Vac, 3.15 A, Delay 99194288
Supply Command Board - F2 (illustration 3) 250 Vac, 0.5 A, Delay 58079685
Supply Command Board - F3 (illustration 3) 150 Vac, 125 A, Fast 91684676
Supply Command Board - F4 (illustration 3) 380 Vac, 10 A, Fast 58079166
Supply Command Board - F5 (illustration 3) 380 Vac, 10 A, Fast 58079166
Supply Command Board - F6 (illustration 3) 250 Vac, 16 A, Fast 58079690
Next to circuit breaker - F1 (illustration 4) 600 Vac, 35 A, Fast 99184154
Next to circuit breaker - F2 (illustration 4) 600 Vac, 35 A, Fast 99184154
Mains Distribution Board - F1 (illustration 5) 250 Vac, 1 A, Delay 58079686
Mains Distribution Board - F2 (illustration 5) 250 Vac, 0.5 A, Delay 58079685
Mains Distribution Board - F3 (illustration 5) 250 Vac, 0.5 A, Delay 58079685
Gantry
PDU Board - F1 (illustration 6) 250 Vac, 6.25 A, Delay 46-170021P60
PDU Board - F3 (illustration 6) 250 Vac, 0.5A, Delay 46-170021P31
PDU Board - F4 (illustration 6) 250 Vac, 2A, Delay 46-170021P30
PDU Board - F5 (see note) (illustration 6) 250 Vac, 125 mA, Delay 5344386-2
PDU Board - F6 (see note) (illustration 6) 250 Vac, 125 mA, Delay 5344386-2
MPCB - F1 (illustration 6) 600 Vac, 20 A, Fast 2387747
MPCB - F2 (illustration 6) 600 Vac, 20 A, Fast 2387747
Note: If you are changing the F5 or F6 fuse on the PDU Board, do the following:
• If the PDU Board Part Number is 2365871-7 or below, order PDU Board 2365871-8 and change the entire PDU Board it according to
Job Card D/R A191 - PDU Board on page 1137.
• If the PDU Board Part Number is 2365871-8, order the fuse 5344386-2 and change it according to this Job Card.
