GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A203 - Lower Optical Fork
Page no. 1171 Chapter 9
JC-DR-A-203.fm
Job Card D/R A203 - Lower Optical Fork Chapter 9
1SUPPLIES
Lower Optical Fork
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 25 minutes
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5 PREREQUISITES
• Raise the arm to its maximum height to access the lower
optical fork (1).
• Switch off the system power.
• Remove the Front cover and the right column cover (Refer
to Job Card PHY A044 - Remove/Reinstall Gantry Covers
on page 523).
• Loosen and remove the Gantry curtain under the arm (refer
to Job Card D/R A208 - Gantry Curtains on page 1193).
1
