GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card CAL A009 - X-Ray Tube mA Measurement
Page no. 1663 Chapter 9
JC-CAL-A-009.fm
Job Card CAL A009 - X-Ray Tube mA Measurement Chapter 9
1SUPPLIES
None
2TOOLS
• Meter for measurement of mA. The meter must be in good condition and possess valid certification.
Suitable meters are:
- Fluke 87 multimeter
- Keithley 35035 mAs meter
- GS Poner 165 mA-mAs meter
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 27 minutes
4 SAFETY PRECAUTIONS
None
5 PREREQUISITES
None
6 CALIBRATION OF X-RAY TUBE MA MEASUREMENT
The objective is to determine the scale factor F/mA between the X-ray tube mA measurement input to
the software and the real X-ray tube mA value.
The default parameter value is F/mA = +1.000E+3 (1000) Hz/mA
CAUTION
DO NOT touch potentiometer P1 on generator kV/mA board 701-PL1 at any point in this
procedure.
