GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A313 - Trackball
Page no. 1427 Chapter 9
JC-DR-A-313.fm
Job Card D/R A313 - Trackball Chapter 9
Three types of Rotative Arm Sets exist, as follows:
• Ergotron A (introduced with V1 Control Stations) - contains one rotative arm support and two exten-
sion (rotative) arms
• Ergotron B (introduced with V2 Control Stations and with early V3 Control Stations) - contains one
rotative arm support and two extension (rotative) arms
• Sisfle (introduced with V3/V4 Control Stations) - contains one rotative arm support and one extension
(rotative) arm
The procedure used in this Job Card vary according to the type of rotative arm you have.
1SUPPLIES
ADS Trackball Kit
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 60 minutes
4 SAFETY PRECAUTIONS
WARNING
Before beginning work, shut down correctly the equipment and switch off the Senographe
system hospital supply circuit breaker. Lock it in the off position or mark it clearly with a
warning sign to prevent others from applying power.
5 PREREQUISITES
Calibrate the new replacement Trackball on a laptop in a quiet area (see Job Card ELE A065 - Trackball
Configuration on page 787).
