GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card CHK A004 - DICOM Printer Adjustments and Checks
Page no. 1741 Chapter 9
JC-CHK-A-004.fm
Job Card CHK A004 - DICOM Printer Adjustments and Checks Chapter 9
1SUPPLIES
None
2TOOLS
Densitometer
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 10 minutes
4 SAFETY PRECAUTIONS.
None
5 PREREQUISITES
The printer must be correctly calibrated.
6 PROCEDURE
6-1 Preparation and Print
1. Install the SMPTE pattern (together with the Test_pattern pattern). To do this, right mouse click on
the Browser background and from the Root Menu that appears, select Service Tools > Install
SMPTE.
To Next Page
