GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A011 - Trackball Option Installation
Page no. 443 Chapter 6
JC-PHY-A-011.fm
Job Card PHY A011 - Trackball Option Installation Chapter 6
1SUPPLIES
ADS Trackball Kit
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 1 hour 30 minutes
4 SAFETY PRECAUTIONS
WARNING
Before beginning work, shut down correctly the equipment and switch off the Senographe
system hospital supply circuit breaker. Lock it in the off position or mark it clearly with a
warning sign to prevent others from applying power.
5 PREREQUISITES
Calibrate the Trackball on a laptop in a quiet area (see Job Card ELE A065 - Trackball Configuration on
page 787).
6 PROCEDURE
1. Unplug and remove the X-ray Console.
2. Remove the Top Cover (see Job Card PHY A040 - Remove/Reinstall Control Station Covers on page
503).
3. Remove the Omega Cover (see Job Card PHY A040 - Remove/Reinstall Control Station Covers on
page 503).
4. Carefully pull on the upper silicone mask (1) to remove it from the rotative arm. Store the upper sili-
