Job Card D/R A222 - Clutch and Cable
Page no. 1227 Chapter 9
JC-DR-A-222.fm
Job Card D/R A222 - Clutch and Cable Chapter 9
1SUPPLIES
Depending on your system configuration:
Clutch (2345968-4)
or
Spare Part Kit Clutch 2345968-4 and Rotation Board 2375488-13 (5265895-2)
Note:
The FRU Spare Part Kit Clutch 2345968-4 and Rotation Board 2375488-13 (5265895-2) compris-
es a V2 Clutch (2345968-4) and Rotation Board (2375488-13). V2 Clutches are only phsically com-
patible with newer V2 Rotation Boards 2375488-12 and above. The first V2 Rotation Boards
(2375488-12) were introduced at IS4-3 Forward Production (system model number 2383168-5).
To determine whether the Gantry already has a compatible V2 Rotation Board that supports the V2
Clutch, check the model number of the system(located on the Generator covers identification labels).
• If the system model number is 2383168-5 or greater, the Gantry contains a V2 Rotation Board. In this
case, order the Clutch (2345968-4) and change the Clutch according to the instructions in this Job
Card.
• If the system model number is 2383168-4-1 or lower, the Gantry does not
contain a V2 Rotation
Board. In this case, order the Spare Part Kit Clutch 2345968-4 and Rotation Board 2375488-13
(5265895-2). Change the Clutch according to the instructions in this Job Card and
also change the
Rotation Board (2375488-13) supplied with the kit. For more information on changing the Rotation
Board, refer to Job Card D/R A221 - Rotation Board on page 1223.
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 60 minutes
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
