GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A292 - Tube Tilt Pivots
Page no. 1397 Chapter 9
JC-DR-A-292.fm
Job Card D/R A292 - Tube Tilt Pivots Chapter 9
1SUPPLIES
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 3 to 4 hours including all calibrations and functional checks
4 SAFETY PRECAUTIONS
WARNING
Be careful when touching the tube housing as its temperature can be up to 80°C
(about 180°F).
5 PREREQUISITES
• Rotate the arm to 90° counterclockwise, placing the tube head at the 9-o’clock position.
• Switch off the Gantry power.
WARNING
The Senographe system must be powered OFF and LOTO applied. Switch OFF the electri-
cal power supply from the Mains Distribution Panel in the room. Apply an appropriate
LOTO padlock and label.
• Remove the tube cover (see Job Card Job Card PHY A044 - Remove/Reinstall Gantry Covers on
page 523).
Part Number Description FRU
5412241 Tube Tilt pivot Kit which includes:
• 2291796 right tube tilt pivot (1x) and
2291797 left tube tilt pivot (1x)
• 99059758 M 5X10 screws (2x) and
2192408 M 3X8/8 A4-70 screws (3x)
FRU orderable
