GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A249 - W304 Cable for Paddle Recognition
Page no. 1319 Chapter 9
JC-DR-A-249.fm
Job Card D/R A249 - W304 Cable for Paddle Recognition Chapter 9
1SUPPLIES
W304 Cable for Paddle Recognition
2TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 60 minutes
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5 PREREQUISITES
• Switch off the Gantry power.
• Remove the Paddle.
• Remove the Paddle Holder cover (refer to Job Card PHY A044 - Remove/Reinstall Gantry Covers on
page 523) for access to the Paddle Recognition cable.
To Next Page
