GE Senographe DS User Manual

Page no. 177 Chapter 3
Component-index.fm GE Healthcare Senographe DS Revision 1 Service Information and Procedures Class A 2385072-16-8EN
FRU/Component Index - Generator Cabinet
FRU/Component Index - Generator Cabinet Chapter 3
Class Component Description Reference Comp. Loc FD Cabl CL FRU Trac D/R
15 Capacitor Unit 2110227 Loc
page
214
FRU Y Trac N D/R
page
1553
15 Capacitor-2200µF 350V 58079856 Loc
page
215
FRU Y Trac N
15 Capacitor-330000µF 63V 99091203 FRU Y Trac N
15 Capacitor 2.5UF 45067136 FRU Y Trac N
15 Capacitor-ALU 100UF 99182146 FRU Y Trac N
15 Diode-Bridge 120A (D26, D27) 91707991 Loc
page
215
FRU Y Trac N
15 Diode-Bridge 60A (D24, D25) 91707990 Loc
page
215
FRU Y Trac N
15 Diode-Module 1.4kV 60A 58079525 Loc
page
214
FRU Y Trac N
15 Electronic Component-Misc 2326402 FRU Y Trac N
15 Electronic Component-Misc 2326401 FRU Y Trac N
15 Fuse, 250 Vac, 1 A, Delay
(F1 on Mains Distribution
Board)
58079686 Loc
page
263
FRU Y Trac N D/R
page
1109
15 Fuse, 600 Vac, 35 A, Fast
(F1/F2 next to Generator S1
Switch and K1 Contactor)
99184154 Loc
page
215
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 3.15 A, Delay
(F1 on Supply Command
Board)
99194288 Loc
page
270
FRU Y Trac N D/R
page
1109
