GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Page no. 215
Location-Gene.fm
3-2-5. Generator with the HV Unit (continued)
Transformer 9kW 52A 415V
Cable REL/CTRS (W10)
Cable PSRS/CTRS (W12)
Line Supply Contactor
Diode DD31N400K
(D24, D25)
Diode DD61N400K
(D26, D27)
Main Emergency switch
Relay 18 A 230 V 22 V
Fuse Holder 2P 60x27 600V
Fast Fuse 27x60 35A
cable (W14)
Capacitor AL 2200µF 350V
600V C 100KA
