GE Senographe DS User Manual

Chapter 3 Page no. 178
Component-index.fm
GE Healthcare Senographe DS Revision 1 Service Information and Procedures Class A 2385072-16-8EN FRU/Component Index - Generator Cabinet
15 Fuse, 250 Vac, 0.5 A, Delay
(F2 on Supply Command
Board, and F2/F3 on Mains
Distribution Board)
58079685 Loc
page
270 &
page
263
FRU Y Trac N D/R
page
1109
15 Fuse, 150 Vac, 125 A, Fast
(F3 on Supply Command
Board)
91684676 Loc
page
270
FRU Y Trac N D/R
page
1109
15 Fuse, 380 Vac, 10 A, Fast
(F4/F5 on Supply Command
Board)
58079166 Loc
page
270
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 16 A, Fast
(F6 on Supply Command
Board)
58079690 Loc
page
270
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 10 A, Delay
(F1 on Mains Distribution
Assembly)
99183979 Loc
page
281
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 5 A, Delay
(F2/F4 on Mains Distribution
Assembly)
99183923 Loc
page
281
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 1.6 A, Delay
(F3 on Mains Distribution
Assembly)
99183925 Loc
page
281
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 1.0 A, Delay
(F5 on Mains Distribution
Assembly)
99183936 Loc
page
281
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 2.5 A, Delay
(F1/F2/F3 on Command Supply
Board)
99194291 Loc
page
251
FRU Y Trac N D/R
page
1109
15 Inductor-Filtering 2X125 UH 45066952 Loc
page
214
FRU Y Trac N
15 Jumper-Red 99171545 Loc
page
216
FRU Y Trac N
15 Transistor-2N 60V 99023151 FRU Y Trac N
Class Component Description Reference Comp. Loc FD Cabl CL FRU Trac D/R
